Features
- Commercial grade performance
- Ideal for hot or cold air transfer
- Powerful long life ball bearing motor
- Rated to 80,000 continuous runtime
- Rated to 30,000 start cycles
- Integrated energy saving back draftstopper
- Ideal for long duct runs
- 2 speed high/low external switch
- Plug and lead included
Mixflow 100 Specification
- Motor Power: 30/25w
- Input: 220-240V
- Air Delivery: 240/190m³/h
- Speed: 2500/2200 RPM
- Noise Level: 37/30 db @ 3m
- Duct Outlet: 100mm
- Fan Size: 100mm
- IP Rating: IPX4
- Installation: Plug and Lead
- Min. install depth: 250mm
Mixflow 150 Specification
- Motor Power: 50/40w
- Input: 220-240V
- Air Delivery: 561/ 438m³/h
- Speed: 2600/2100 RPM
- Noise Level: 47/39 db @ 3m
- Duct Outlet: 150mm
- Fan Size: 150mm
- IP Rating: IPX4
- Installation: Plug and Lead
- Min. install depth: 280mm
Mixflow 200 Specification
- Motor Power: 130/105W
- Input: 220-240V
- Air Delivery: 852 / 753m³/h
- Speed: 2500/2200 RPM
- Noise Level: 53/45 db @ 3m
- Duct Outlet: 200mm
- Fan Size: 200mm
- IP Rating: IPX4
- Installation: Plug and Lead
- Min. install depth: 300mm
Data Sheet
